Electrode Film Coating Machine with Dryer
Model: MR-TMH250
1. The MR-TMH250 Film coating machine with dryer is used for varies kinds of materials coating.
2. It is supplied with vacuum pump and heating system, having an precision heating temperature upto 200℃.
3. The film coating machine is mainly used for lithium battery electrode coating for coin cell assemble and pouch cell research.
4. Build-in oil-less vacuum pump make the machine with small volume and less noise.
5. New designed Touch Screen control make the operating more easy and simple
Features
* Use large area uniform heating to ensure high temperature uniformity in the cavity;
* Flat coating, motor driven blade coating, coating speed is stable and adjustable;
* Adjustable film speed, vacuum aluminum plate can quickly place or remove copper foil, aluminum foil etc., built-in vacuum pump or access external vacuum source, the substrate absorbs no deformation;
* Standard filming device, high coating precision, adjustable coating thickness;
* Can be used in the glove box, easy to operate and small size, saving space;
* PLC Touch screen control, easy to operate.
Specifications
|
Model |
Automatic Film Coating Machine with Dryer MR-TMH250 |
|
Source Voltage |
AC110V-240V, 50/60HZ |
|
Effective coating area (can be customized) |
150mm W *250mm L |
|
Power |
650W |
|
Coating Speed |
0-100mm/s, Step-less transmission Accuracy: 10mm/sec |
|
Advantages |
Supply with dry function, vacuum pump |
|
Stroke Length |
10 - 250 mm adjustable by using Adjustable Position Switch |
|
Platform |
Aluminum alloy flat vacuum chuck Vacuum Chuck Dimensions: 365mm(L) * 200mm(W)*30mm(T) |
|
Slicker Width |
0-150mm |
|
Slicker Adjustable Range |
0.01-3.5mm |
|
Heating Dry System |
RT-200°C, Digital temperature controller |
|
Temperature Control Accuracy |
±1°C |
|
Dimension |
500*350*320mm |
|
Weight |
About 40kg |
|
Package Size |
790*540*600mm |
|
Package Weight |
65kg |
|
Warranty |
One Year limited warranty with lifetime support |
|
Additional Feature |
1. Built in vacuum pump 2. Heating system : Installed on the top cover Built in digital temperature controller with accuracy of +/-1°C. Suspension support helps open cover easily and safely. Max. Heating Rate:10°C/min Max. Heating Temp.:200°C 3. One 150mm width micrometer adjustable film applicator Traverse Pusher is included for pushing the Film Applicator to ensure the constant coating speed |
