Name: Battery Electrolyte Diffusion Chamber
Brand: MRBEST
SKU: 222516396

Battery Electrolyte Diffusion and Degassing Chamber for Cylindrical Cell Assembly

Battery Electrolyte Diffusion Chamber

mR-JZ300

MR-JZ300 electrolyte diffusion & degassing chamber is specifically designed for professional Cylindrical Cell Research. It is mainly used for removing air from the electrolyte after it's been injected into the Cylinder Li-ion cell or after the formation for final sealing under a vacuumed condition. It is easy to operate and suitable for all types of batteries (especially polymer pouch battery and cylinder battery). Unique periods of vacuum control system allows electrolyte to thoroughly saturate the electrodes to ensure the best battery charging-discharging performance.

features

* Bell-type structure, cylinder driven, fully welded and no leakage;
* The vacuum degree can be maintained stably and the electrode piece can absorb the electrolyte well;
* Use multi-stage cycle method for vacuum storage, and the time period and number of stages can be set;
* The front glass window design allows researchers to observe internal product changes;
* The control box and the vacuum chamber are designed separately, and the vacuum chamber can be placed in the glove box for operation.

Specifications

Model	Battery Electrolyte Diffusion Chamber MR-JZ300
Inner Chamber Size	L325mmW220mmH170mm
Product Dimensions	1. Vacuum Box: 500mm(L) x 350mm(W) x 630mm(H) 2. Control Unit: 460mm(L) x 220mm(W) x 340mm(H)
Power Supply	110-240 V, Single Phase 50/60Hz
Max. Power	100W
Compressed Air	0.5-0.8Mpa
Chamber Body	12mm thick Aluminum case with observation window
Gas Filling Rate	<= 5 psi
Air Pressure Range	0 - 1 Mpa (0 - 99 psi) Adjustable
Vacuum Level	1. Vacuum condition remains stable, vacuum degree and vacuum circulation times can be set independently 2. Vacuum mode (once or twice) can be selected 3. Easy program setting for specific vacuum condition 4. -0.9 - 0 kPa adjustable
Air Inflation Time	0 - 99.99 sec
Vacuum Condition Hold Time	0 - 99.99 sec
Operation Temperature	-20 to 40 ℃
Warranty	One Year limited warranty with lifetime support
Net Weight	50KG
Application Notes	1. KF25 Feedthrough is included to allow operation inside Glove box. 2. Such a Feedthrough ensures air-tightness of glove box.
