Shenzhen Meirui Zhida Technology Co., Ltd. is one of the leading manufacturers and suppliers of manual horizontal roller press machine in China, featured by quality products and low price. Welcome to buy bulk manual horizontal roller press machine made in China here from our factory. If you have any enquiry about pricelist and quotation, please feel free to email us.
Manual Horizontal Roller Press Machine for battery electrode calendering
Model：MR-SG100W
Manual Horizontal Roller Press Machine MR-SG100W is used for battery electrode rolling press research after coating and drying. It is a bench-top manual rolling press machine with 100mm width roller, and easy to operate.
Features
* Rolling pressing speed can be adjustable.
* High hardness roller, >HRC62
* Forward & backward are available.
* Manual operate, saving power.
Specifications
|
Model |
Manual Horizontal Roller Press Machine MR-SG100W |
|
Roller Diameter |
2-Φ96mm |
|
Roller Cylindricity |
≤±2um |
|
Roller Hardness |
HRC62 |
|
Roller Finish |
≥Ra0.4 |
|
Rolling Thickness |
0-2mm adjustable |
|
Rolling Width |
0-100mm (accept customized) |
|
Operation Mode |
Manual |
|
Feeding Speed |
0-40mm/ s according to the hand running speed |
|
Dimension |
L400mm * W300mm * H330mm |
|
Weight |
50KG |
