Planetary Ball Mill Machine For Lithium Ion Battery Slurry Preparation
Model: MR-XQM-0.4A
Product Instruction
1. Planetary ball mill is necessary equipment for mixing, fine grinding, sample preparing, nano-materials dispersing, new product developing and preparing small volume high-tech material production.
2. The Planetary ball mill is small, full-featured, high efficiency and low noise which is the ideal equipment for scientific research units, institutions of higher learning, corporate laboratories to obtain micro particle research samples. (Four samples for each experiment).
3. It can be equipped with vacuum ball mill; the sample can be ground under vacuum. It is widely used in geology, mining, metallurgy, electronics, building materials, ceramics, chemicals, light industry, medicine, beauty, environmental protection and other departments.
4. It can set the speed, forward and reverse rotation time, and the total grinding time according to process requirement.
Optional Ball and Jar
1. Material of ball milling tank: stainless steel, agate, corundum, tungsten carbide, nylon, zirconia, polytetrafluoroethylene, lined with polyurethane and so on; The principle of choice is that the material of the ball mill can not affect the appearance of the material to be ground; Grinding easy to oxidation, must be air-insulated materials, you can use vacuum ball mill tank.
2. Grinding ball material are: chrome steel, stainless steel, agate, alumina, zirconia, Selection principle is the grinding ball material on the material to be polished does not affect the appearance of pollution; Grinding ball material density and hardness must be larger than the abrasive material; Ball mill specifications are: Φ5, Φ8, Φ10, Φ15, Φ20
Working principle
MR-XQM series of variable frequency planetary ball mill has four ball grinding tanks installed on one turntable. When the turntable rotates, the tank axis makes planetary movements, the balls and samples inside the tanks are impacted strongly in high speed movement, and samples are eventually ground into powder. Various kinds of different materials can be grinding and mixing by the mill with dry or wet method. The size of ground powder can be reduced to as small as 0.1 micrometer.
Specifications
|
Model |
Planetary Ball Mill Machine MR-XQM-0.4A |
|
Grinding tank volume (L) |
100ml*4 |
|
Grinding tank material |
Stainless Steel, Optional hard steel, zirconia, agate, corundum, tungsten carbide, nylon, polyurethane, PTFE, etc. |
|
Grinding media |
Stainless steel, Optional agate, zirconia, corundum, etc. |
|
Maximum loading per tank |
Material and grinding medium does not exceed two-thirds of the volume |
|
Feeding material size |
Soil material ≤ 10 mm, other materials ≤ 3 mm |
|
Discharge material size |
Min 0.1um |
|
Rotating speed |
Revolution 45-435 r / min, Rotation 90-870 r / min |
|
Speed ratio (revolution: rotation) |
1:2 |
|
Speed mode |
Frequency, programmable stepless speed regulation, manual, automatic timing forward and reverse |
|
Transfer method |
Gear drive |
|
Working Voltage |
220V |
|
Motor power and variable frequency power |
0.75Kw |
|
Way of working |
Two or four cans work at the same time |
|
Maximum continuous operating time |
72hours |
|
Machine Size |
500*300*340mm |
|
Weight (not include Jars and Ball ) |
30kg |
Picture for reference
